Let’s talk about Google Vision API and how to write a simple java program to extract Text from an Image

By registering for Google Cloud’s vision API you can access just that with an API key.

<project xmlns="http://maven.apache.org/POM/4.0.0"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">





import com.google.api.gax.core.FixedCredentialsProvider;
import com.google.auth.oauth2.GoogleCredentials;
import com.google.cloud.storage.Storage;
import com.google.cloud.storage.StorageOptions;
import com.google.cloud.vision.v1.*;
import com.google.cloud.vision.v1.Feature.Type;
import com.google.common.collect.Lists;
import com.google.protobuf.ByteString;
import java.io.FileInputStream;
import java.io.IOException;
import java.util.ArrayList;
import java.util.List;

public class TextExtractionDemo {
public static void main(String... args) throws Exception {

GoogleCredentials credentials = GoogleCredentials.fromStream(new FileInputStream("<PATH_TO_API_KEY_FILE>"))
Storage storage = StorageOptions.newBuilder().setCredentials(credentials).build().getService();

detectDocumentText("<PATH_TO_IMAGE_FILE>", credentials);

public static void detectDocumentText(String filePath, GoogleCredentials credentials) throws IOException {
List<AnnotateImageRequest> requests = new ArrayList<>();

ByteString imgBytes = ByteString.readFrom(new FileInputStream(filePath));

Image img = Image.newBuilder().setContent(imgBytes).build();
Feature feat = Feature.newBuilder().setType(Type.DOCUMENT_TEXT_DETECTION).build();
AnnotateImageRequest request =

ImageAnnotatorSettings imageAnnotatorSettings =

// Initialize client that will be used to send requests. This client only needs to be created
// once, and can be reused for multiple requests. After completing all of your requests, call
// the "close" method on the client to safely clean up any remaining background resources.
try (ImageAnnotatorClient client = ImageAnnotatorClient.create(imageAnnotatorSettings)) {
BatchAnnotateImagesResponse response = client.batchAnnotateImages(requests);
List<AnnotateImageResponse> responses = response.getResponsesList();

for (AnnotateImageResponse res : responses) {
if (res.hasError()) {
System.out.format("Error: %s%n", res.getError().getMessage());

// For full list of available annotations, see http://g.co/cloud/vision/docs
TextAnnotation annotation = res.getFullTextAnnotation();
for (Page page : annotation.getPagesList()) {
String pageText = "";
for (Block block : page.getBlocksList()) {
String blockText = "";
for (Paragraph para : block.getParagraphsList()) {
String paraText = "";
for (Word word : para.getWordsList()) {
String wordText = "";
for (Symbol symbol : word.getSymbolsList()) {
wordText = wordText + symbol.getText();
blockText = blockText + paraText;
pageText = pageText + blockText;
System.out.println("Complete annotation:");
  • Face detection
  • Landmark detection
  • Label detection
  • OCR for handwritten text
